Digital Taper Gage
Digital Taper Gage
Easily check the size of openings, gaps, slots, or grooves with curved or tapered surfaces of your part and quickly export you data via Bluetooth® technology.
The latest addition to Sylvac's product lineup is their Taper Gage Smart, designed for precise and efficient gap measurements.
If you have a gap, Sylvac have the taper gage for you!
Key features
- Patented Design: Innovative technology for gap width measurement
- Wireless Digital Connectivity: Integrated Bluetooth® for seamless data export
- Quick Measurements: One-push operation for repetitive tasks such as turbine blading and rotor alignment
- Durable & Reliable: IP67-rated for protection against water, coolants, and lubricants
- Exceptional Precision: Ensures accurate results for radial and axial gap alignment
Applications
The Taper Gage Smart is the ultimate solution for gaps with space constraints, particularly in industries such as:
- Automotive
- Aviation
- Power Generation
- Rotor Alignment
This tool is perfect for alignment of tapered surfaces, including openings, slots, and grooves.
| Specification | 918-0005 | 918-0012 | 918-0025 |
|---|---|---|---|
| Measurement capacity (mm) | 0.5 – 5.5 | 0.5 – 17.5 | 12.5 – 28.5 |
| Repeatability (μm) | 10 | 10 | 10 |
| Max. error G (μm) | 30 | 30 | 30 |
| Resolution (mm) | 0.01 | 0.01 | 0.01 |
| Protection rating according to IEC 529 | IP67 | IP67 | IP67 |
| Connection type (instrument to device) | Bluetooth® wireless technology | Bluetooth® wireless technology | Bluetooth® wireless technology |
| Weight (g) | 270 | 382 | 510 |
