Scan-to-CAD

Scan-to-CAD is a post-treatment software from Creaform that directly integrates into Creaform.OS, and enables finalizing 3D scan data to use directly in any 3D printing or CAD software. Scan-to-CAD provides the simplest and fastest path from 3D scans to your computer-aided design or additive manufacturing workflow.

A great addition to any Creaform 3D scanner, Scan-to-CAD is simple but powerful, including only the features necessary to complement your CAD software. You already have all the design and modelling capabilities in your software: Scan-to-CAD only provides the tools you need for a quick and seamless integration into your scan-based design process.

Scan-to-CAD provides simple, yet efficient tools required to prepare the 3D scan mesh for reverse engineering or 3D printing.

STEP 1: Edit mesh

STEP 2: Align

STEP 3: Extract entities

STEP 4: 2D Sketching (Scan-to-CAD Pro)

STEP 5: 3D Modelling (Scan-to-CAD Pro)

STEP 6: Transfer to CAD
