VXinspect™ is an intuitive and powerful 3D inspection software designed for manufacturing companies using a Creaform 3D scanner to conduct first article inspection (FAI) and production control
VXinspect™ is an intuitive and powerful 3D inspection software designed for manufacturing companies conducting first article inspection (FAI) and production control. VXinspect features all the essential functionalities required to build a measurement sequence, resulting in high efficiency when controlling multiple parts. A built-in centralized panel displays all the information you can choose to export in the final report. Like other Creaform software modules, VXinspect is directly integrated into VXelements™, the Creaform 3D software platform and application suite. It provides the simplest integration of probing, 3D scanning and photogrammetry measurements to meet industry requirements for all quality control applications.
The combination of Creaform technologies with VXinspect offers the metrology software for shop‑floor environments. With its intuitive interface, it is the best solution for all inspection workflow, with no compromises made on measurement quality and GD&T requirements.
VXinspect has been entirely rethought in order to make it suitable for users of every type, with a wide range of expertise levels and workflow types. The following enhancements were made:
- Integrate photogrammetry, by supporting both the Creaform MaxSHOT 3D and the C‑Track as measuring devices. Inspections cans be performed directly from positioning targets and can additionally use a combination of targets and scan or probe data.
- Introduce a Quick Colormap feature, with a best fit photogrammetric‑model sent to the CAD file in order to deliver the colormap.
- Displaying a real-time visualization (with CAD model) during the target acquisition phase.
- Supporting inspections from scan data, by integrating a new VXelements workflow as well as introducing interactivity in the 3D Viewer.
|
STEP 1: Measure |
STEP 2: Import |
STEP 3: Align |
|
VXinspect works in multiple measurement modes by seamlessly integrating photogrammetry, single-point touch probe, and non-contact measurement (scan).
|
VXinspect supports CAD import or any mesh for direct measurement comparisons with reference 3D models, leading to a better understanding of manufacturing defects.
|
As an object’s position and orientation in space are crucial during the inspection, VXinspect includes a complete alignment toolset to fulfill inspection requirements and generate more accurate results.
|
|
STEP 4: Analyse |
STEP 5: Report |
STEP 6: Repeat |
|
Thanks to its sophisticated algorithms and calculation methods, VXinspect combines simple, yet powerful tools and features to fully analyze the inspected parts.
|
VXinspect makes it easy to create and share inspection reports in multiple formats.
|
When a repeat inspection is required, VXinspect can quickly move from one part to the next with minimal steps.
|
